Description
GIGABYTE Intel® B860 Chipset for LGA 1851; 4x DDR5; 2x M2; HDMI/DP ; ATX.
Specifications
- ATX Form Factor
- Intel B860 Chipset, Socket LGA 1851
- Supports Intel Core Ultra Series 2 Processors
- 4x DDR5 DIMM Slots, Supports Up To 256GB (4x64GB)
- Supports Up to DDR5 9066 (OC)
- Supports CUDIMM DDR5 Modules
- Supports Intel XMP 3.0 Memory Modules
- 1x PCIe 5.0 x16 Slot (x16 Physical)
- 4x PCIe 4.0 x1 Slots (x16 Physical)
- 1x M.2 25110/2580 PCIe 5.0 x4 NVMe SSD Slot
- 1x M.2 25110/2580 PCIe 4.0 x4 NVMe SSD Slots
- 4x SATA 3.0 Ports
- Supports Front Panel USB 5Gbps Type C Port
- 1x USB 20Gbps Type C Port
- 1x USB 10Gbps Type A Port
- 4x USB 2.0 Type A Ports
- 1x HDMI 2.1 (TMDS), 1x DisplayPort 2.1 Port
- 3x 3.5mm Audio Jacks
- 1x PS/2 Combo Port (Keyboard, Mouse)
- 2x Antenna Connectors
- Realtek 2.5 Gigabit Ethernet RJ 45 LAN
- Intel WiFi 6E Tri Band Adapter, Bluetooth 5.3
- Realtek ALC892 High Definition Audio CODEC
- 8+1+2 Hybrid VRM Solution
- Gigabyte Q Flash Plus BIOS Button
- ASUS Q LED Diagnostic LEDs
- Gigabyte RGB Fusion
- Gigabyte Control Center App
- Supports Windows 11 64 Bit
