Hikvision In-Ceiling Access Point 1800 Mbps Dual-band Wi-Fi 5 Gigabit

Description

Hikvision In-Ceiling Access Point 1800 Mbps Dual-band Wi-Fi 5 Gigabit in-Ceiling indoor AP 2×2 MIMO 1 Gigabit port with 1 PoE in

Specifications

• Installation Mode: Desk-Mounted,Wall-Mounted,Ceiling Mounting
• Working Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Working Humidity: 5% to 95% (no condensation)
• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
• Storage Humidity: 5% to 95% (no condensation)
• Product Dimensions (W × H × D): 220 mm × 220 mm × 39 mm (8.66” × 8.66” × 1.54”)
• Packing List: 1200 M Access Point ×1,Screw Pack × 1,Quick Start Guide ×1,Regulatory Compliance and Safety Information × 1
• Power Consumption: Max. 11.35 W
• Interface: 1 × Gigabit RJ45 uplink port
• Power Supply: IEEE 802.3af/at POE,12 VDC 1.5 A
• LED Indicator: Yellow/green/blue for different working states, flashing mode
• Reset Button: Hardware Resetting Button
• Maximum Number of Clients: 256
• Recommended Number of Clients: 80
• Maximum Number of SSIDs: 8
• Working Frequency Band: radio 1: 5G(11a/an/ac), radio 2: 2.4G(11b/g/gn)
• Wi-Fi Standards: Wi-Fi 5
• Wi-Fi Speed: 2.4 G: 300 Mbps,5 G: 867 Mbps
• Spatial Streams: 2.4 GHz, 2 × 2 , MU-MIMO, 5 GHz, 2 ×2 , MU-MIMO
• Channel Width: 2.4 GHz: Auto/20 /40 MHz,5 GHz: Auto/20 /40 /80/MHz
• Number of Antennas: 2.4 GHz：2；5 GHz：2
• Antenna Type: Built-in omnidirectional antennas
• Antenna Gain: 2.4 GHz: 3 dBi,5 GHz: 4 dBi
• Transmit Power: 20 dBm
• Modulation Technology: OFDM：BPSK@6/9Mbp、QPSK@12/18Mbps、16-QAM@24Mbps、64-QAM@48/54Mbps; DSSS：DBPSK@1Mbps、DQPSK@2Mbps、CCK@5.5/11Mbps; MIMO-OFDM （11n）：MCS 0-15; MIMO-OFDM （11ac）：MCS 0-9
• WLAN Security: WAP-PSK,WAP2-PSK,WPA-WAP2-PSK,Blocklist & Allowlist,Support Multiple encryption key triggered dynamic unicast/multicast key update,Support Open system/shared key authentication,Support wireless endpoint access,Support SSID and VLAN b…
• Management & Maintenance: Centralized AC management
• Version Upgrade: upgrade on Web
• EMC: CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
• Safety: CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017),UL (UL 60950-1)
