Description
Hikvision Balun Pair With Pigtail
Specifications
- Transmission Signal: 1 channel
- Transmission Distance: Max 350m
- Category Type: UTP CAT 5E/ 6
- Coaxial Video Connector: BNC-M
- Twisted-pair Video Connector: Tool-less push-pin terminal block
- Compatible Format: HD-TVI/TVI/AHD/CVBS
- Resolution: 720P/960P/1080P/3MP/4MP/5MP/8MP
- Ant-interference: >60dB
- ESD: Contact discharge electricity level3; air discharge electricity level3; Per: IEC61000-4-2
- Coaxial Cable Connector: 2KV(common-code) Per:IEC61000-4-5
- UTP Cable Connector: 2KV(different-code), ; 2KV(common-code); Per:IEC61000-4-5
- BNC Male: 75 ohms
- UTP Cable: 100 ohms
- Shell: ABS engineering plastic
- Color: Black
- Weight: 39 g
- MTBF: >10000 h
- Operating Temperature: -20º ~55º C
- Storage Temperature: -40º ~ 150º C
- Humidity: 0~95% (non-condensing)
