Hikvision 16-Channel 1080P Acusense Mini 1U DVR

Description

Hikvision 16-Channel 1080P Acusense Mini 1U DVR

Specifications

• Line Crossing Detection/Intrusion Detection: 4-ch
• Facial Detection and Capture: Face picture detection, face picture search
• Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;; Quick search by object or event type …
• IP Video Input: 2-ch (up to 18-ch); Enhanced IP mode on: ; 8-ch (up to 24-ch), each up to 4 Mbps; Up to 6 MP resolution; Support H.265+/H.265/H.264+/H.264 IP cameras
• Analog Video Input: 16-ch; BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• HDTVI Input: 3K(2960 x 1665)@25/20 fps, 3K(3328×1504)@20fps, 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 2K(2304 x 1296)@20 fps, 1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps
• AHD Input: 5 MP(2592 × 1944)@20 fps,4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• HDCVI Input: 3K(2880 × 1620)@20/25 fps, 5 MP(2592 × 1944)@20 fps,4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps
• CVBS Input: PAL/NTSC
• HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
• Audio Input: 1-ch(up to 4-ch is optional), RCA (2.0 Vp-p, 1 KΩ), 4-ch via coaxial cable
• Audio Output: 1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
• Synchronous playback: 16-ch
• Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding Resolution: When 1080p Lite mode is not enabled: ; 2K/3K lite/5 MP lite/4 MP lite/3MP/1080p/720p/VGA/WD1/4CIF/CIF;; When 1080p Lite mode is enabled: ; 2K/3K lite/5 MP lite/4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
• Frame Rate: Main stream:; When 1080p Lite mode not enabled: ; For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps; For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps; For 4 MP …
• Video Bitrate: 32 Kbps to 6 Mbps
• Dual-stream: Support
• Stream Type: Video, Video & Audio
• Audio Compression: G.711u
• Audio Bitrate: 64 Kbps
• Remote Connection: 128
• Total Bandwidth: 128 Mbps
• Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF,ISUP
• Network Interface: 1, RJ45 10M/100M/1000M ; self-adaptive Ethernet interface
• SATA: 1 SATA interface
• Capacity: Up to 10 TB capacity for each disk
• USB Interface: Real panel: 2 × USB 2.0
